GPMA1552 Factor 3D 1M Sport EP ARF 38"
Regular price
$119.99 USD
Regular price
$169.99 USD
Sale price
$119.99 USD
Unit price
per
Couldn't load pickup availability
GPMA1552 Factor 3D 1M Sport EP ARF 38". Simple design, spectacular performance.
What the Factor 3D lacks in size, it makes up for in maneuverability. This purpose-built flier can do just about everything: harriers, waterfalls, torque rolls – even smooth sport aerobatics! Best of all, the Factor 3D does it with economical components. And like all other Great Planes aircraft, it's easy to assemble, thanks to top-notch craftsmanship, a two-piece wing and quality hardware.
Compact size, unmatched convenience.
Removable wing panels.
Offers a wide flight envelope.
Assembles quickly and easily. FEATURES
Construction: Balsa and ply
Wing: Two-piece with carbon fiber joiner tube
Aileron Control: Dual servo
Canopy: Secures to fuselage with magnets
Cowl: Molded plastic
Landing Gear: Two-piece prebent aluminum with 1.5" (38mm) main
wheels and 1" (25.4mm) tailwheel, steel tailwheel wire
Wheel Pants: Molded plastic
Spinner: White plastic 1.5" (38mm) diameter
Motor Mount: Plywood
Warranty: Great Planes Model Manufacturing Company guarantees this
kit to be free from defects in both materials and workmanship at
the date of purchase. This warranty does not cover any parts
damaged by use or modification.
INCLUDES
Factor 3D Sport Airplane with Landing Gear, Wheel Pants, Spinner
Wing Joiner, Motor Mount, and Instructions
REQUIREMENTS
Radio: 4-channel with four micro servos
Motor: 35-30-1250kV outrunner brushless
ESC: 35A, for brushless motors
Y Harness: One
16" Extensions: Two for rudder and elevator servos
Battery: 11.1V 2200mAh LiPo
Battery Charger: Compatible with selected battery
Propeller: 10x4.5 or 10x4.7 slow flyer
Building and field equipment
SPECIFICATIONS
Wingspan: 38" (965mm)
Wing Area: 375 sq in (24.3 sq dm)
Wing Loading: 10.8-12.3 oz/sq ft (33-38 g/sq dm)
Weight: 28-32 oz (795-905 g)
Length: 41.5" (1,055mm)
Center of Gravity (CG): 4-1/4" (108mm) back from the leading edge of
the wing at the fuselage side
Control Throws: Low Rate High Rate 3D
Elevator 1-1/4" (32mm) 19° 1-3/4" (44mm) 27° 2-1/4" (57mm) 35°
Rudder 1-1/4" (32mm) 17° 1-1/2" (38mm) 19° 2-3/4" (70mm) 36°
Ailerons 5/8" (16mm) 13° 1" (25mm) 25° 1-1/4" (32mm) 27°
What the Factor 3D lacks in size, it makes up for in maneuverability. This purpose-built flier can do just about everything: harriers, waterfalls, torque rolls – even smooth sport aerobatics! Best of all, the Factor 3D does it with economical components. And like all other Great Planes aircraft, it's easy to assemble, thanks to top-notch craftsmanship, a two-piece wing and quality hardware.
Compact size, unmatched convenience.
Removable wing panels.
Offers a wide flight envelope.
Assembles quickly and easily. FEATURES
Construction: Balsa and ply
Wing: Two-piece with carbon fiber joiner tube
Aileron Control: Dual servo
Canopy: Secures to fuselage with magnets
Cowl: Molded plastic
Landing Gear: Two-piece prebent aluminum with 1.5" (38mm) main
wheels and 1" (25.4mm) tailwheel, steel tailwheel wire
Wheel Pants: Molded plastic
Spinner: White plastic 1.5" (38mm) diameter
Motor Mount: Plywood
Warranty: Great Planes Model Manufacturing Company guarantees this
kit to be free from defects in both materials and workmanship at
the date of purchase. This warranty does not cover any parts
damaged by use or modification.
INCLUDES
Factor 3D Sport Airplane with Landing Gear, Wheel Pants, Spinner
Wing Joiner, Motor Mount, and Instructions
REQUIREMENTS
Radio: 4-channel with four micro servos
Motor: 35-30-1250kV outrunner brushless
ESC: 35A, for brushless motors
Y Harness: One
16" Extensions: Two for rudder and elevator servos
Battery: 11.1V 2200mAh LiPo
Battery Charger: Compatible with selected battery
Propeller: 10x4.5 or 10x4.7 slow flyer
Building and field equipment
SPECIFICATIONS
Wingspan: 38" (965mm)
Wing Area: 375 sq in (24.3 sq dm)
Wing Loading: 10.8-12.3 oz/sq ft (33-38 g/sq dm)
Weight: 28-32 oz (795-905 g)
Length: 41.5" (1,055mm)
Center of Gravity (CG): 4-1/4" (108mm) back from the leading edge of
the wing at the fuselage side
Control Throws: Low Rate High Rate 3D
Elevator 1-1/4" (32mm) 19° 1-3/4" (44mm) 27° 2-1/4" (57mm) 35°
Rudder 1-1/4" (32mm) 17° 1-1/2" (38mm) 19° 2-3/4" (70mm) 36°
Ailerons 5/8" (16mm) 13° 1" (25mm) 25° 1-1/4" (32mm) 27°
